Dahua รุ่น HAC-HDW1000M-S31MP HDCVI IR Eyeball Camera
900 รวมภาษี บาท
| HAC-HDW1000M-S3 4 in 1 |
| 1MP HDCVI IR Eyeball Camera |
| The parameters and datasheets below can only be applied to 1000-S3 series |
| Max 30fps@720P |
| HD and SD output switchable |
| lens (2.8mm optional) |
| Max. IR length 30m Smart IR |
| IP67 DC12V |
| รับประกัน 2 ปี |
Description
| Image Sensor | 1/4″ CMOS |
| Effective Pixels | 1280(H)×720(V) 1MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25~1/100000s |
| NTSC: 1/30~1/100000s | |
| Minimum Illumination | 0.05Lux/F2.0 30IRE 0Lux IR on |
| S/N Ratio | More than 65dB |
| IR Distance | Up to 30m (98feet) |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 12 |
| Lens | |
| Lens Type | Fixed lens / Fixed iris |
| Mount Type | Board-in |
| Focal Length | 3.6mm (2.8mm Optional) |
| Max Aperture | F2.0 |
| Angle of View | H: 60° (83.4°) |
| Focus Control | N/A |
| Close Focus Distance | 600mm (500mm) |
| 23.6” (19.69”) | |
| Pan / Tilt / Rotation | |
| Pan/Tilt/Rotation | Pan: 0° ~ 360° |
| Tilt: 0° ~ 90° | |
| Rotation: 0° ~ 360° | |
| Video | |
| Resolution | 720P (1280×720) |
| Frame Rate | 25/30fps@720P |
| Video Output | 1-channel BNC high definition video output / CVBS video output (Can switch) |
| Day/Night | Auto (ICR) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / DWDR |
| WDR | DWDR |
