| Image Sensor |
1/3” 3Megapixel CMOS |
| Effective Pixels |
2304(H)x1536(V) |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3(4)~1/100000 |
| Min. Illumination |
0.9lux/F1.2(color) 0lux/F1.2(IR on) |
| Max. LEDs Length |
10m |
| Day/Night |
Auto(ICR) / Color / B/W |
| Backlight Compensation |
BLC / HLC / DWDR |
| Lens |
| Focal Length |
2.3mm |
| Compression |
H.264/H.264B/H.264H/MJEPG |
| Resolution |
3MP(2304×1296)/1080P/720P/VGA/QVGA |
| Frame Rate |
Main Stream |
3MP(1~20fps)/1080P/720P(1~30fps) |
| Sub Stream |
VGA/QVGA(1~30fps) |
| Bit Rate |
H.264: 32Kbps～8Mbps |
| Wi-Fi |
Wi-Fi(IEEE802.11b/g/n)
50m(open field) |
| Smart Phone |
iPhone iPad Android Windows Phone |
| Memory Slot |
Micro SD up to 128GB |
| USB |
Micro USB |
| Power Supply |
DC 5V |
| Power Consumption |
<4.6W |
| Working Environment |
-10°C~+45°C Less than 95%RH |
| Dimensions(W×D×H) |
76mm*65mm*107mm |
| Weight |
0.14Kg(0.36Kg with package) |
