ER7212PC
5,200 รวมภาษี บาท
ER7212PC
- 3-in-1 Gateway: Integrates 8× PoE+ ports and centralized management capability. Up to 10 EAPs can be centrally managed.
- Up to 12× Gigabit ports bring high-speed network.
- Up to 4× WAN Ethernet ports for a stable network.
- Centralized Management: Cloud access and the Omada app for easy management.
- Highly Secure VPN: Supports IPsec VPN/ OpenVPN / L2TP / PPTP VPN.
- Easy Installation: Fanless and compact design for desktop and wall mounting.
Description
ER7212PC
| Standards and Protocols | • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q |
| • TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, SNMP | |
| Interface | • 2 Gigabit SFP WAN/LAN ports |
| • 1 Gigabit WAN port | |
| • 1 Gigabit LAN/WAN port | |
| • 8 Gigabit LAN ports | |
| Network Media | • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) |
| EIA/TIA-568 100Ω STP (Max 100 m) | |
| • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) | |
| EIA/TIA-568 100Ω STP (Max 100 m) | |
| • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) | |
| Fan Quantity | Fanless |
| Button | Reset Button |
| Power Supply | 53.5VDC/2.43A Adapter |
| PoE Budget | 8 ports PoE+ output, 110 W PoE Budget |
| Flash | 8Mb Nor + 4 GB EMMC |
| DRAM | 1 GB DDR3 |
| LED | PWR, SYS, CLOUD, PoE Max, SFP 1, SFP 2, WAN (Speed, Link/Act), LAN (Speed, Link/Act) |
| Dimensions ( W x D x H ) | 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) |
| Protection | 4 kV surge protection |
| Enclosure | Steel |
| Mounting | Desktop/Wall-mount |
| Max. Power Consumption | • 133.2W with PoE Max |
| • 13.88W without PoE |
-
